Tektronix DSA70000D Series Technical Reference

Analog bandwidth with X10
passive probe, typical, <4 GHz
models
Full bandwidth, operating ambient of ≤ 30 °C (86 °F), derated by 1% for each °C above 30 °C
(86 °F)
SCALE range Bandwidth
5 mV/div to 10 V/div DC to 500 MHz
2 mV/div to 4.98 mV/div DC to 300 MHz
1 mV/div to 1.99 mV/div DC to 175 MHz
Analog bandwidth selections
<4 GHz models
20 MHz, 250 MHz, and Full
Lower frequency limit AC coupled
<4 GHz models
10 Hz when 1 MΩ, AC coupled. The limit is reduced by a factor of 10 when 10X, passive probes
are used.
Upper frequency limit 250 MHz
bandwidth limited <4 GHz models
250 MHz
Upper frequency limit 20 MHz
bandwidth limited <4 GHz models
20 MHz
Passband flatness, BWE, typical
MSO/DPO73304DX, MSO/
DPO72504DX, MSO/
DPO72304DX
Step settings Temperature constraint
62.5 mV
FS
, 100 mV
FS
, 200 mV
FS
, 500 mV
FS
,
1 VFS, 2 V
FS
, and 5 V
FS
± 0.5 dB from DC to 50% of nominal bandwidth.
± 1.5 dB from 50% to 80% of nominal
bandwidth.
At 25 °C
All other gain settings
± 1.0 dB from DC to 50% of nominal bandwidth
± 2.0 dB from 50% to 80% of nominal
bandwidth.
MSO/DPO72004C, MSO/
DPO71604C, MSO/DPO71254C
Use the Temperature variation table to determine the amount of performance derating above the
temperature limit.
Step settings Temperature constraint
100 mVFS, 200 mVFS, 500 m VFS, 1 VFS, and
2.5 VFS
± 0.5 dB from DC to 50% of nominal bandwidth.
± 1.5 dB from 50% to 80% of nominal
bandwidth.
At 25 °C
Non-step settings
± 1.0 dB from DC to 50% of nominal bandwidth
± 2.0 dB from 50% to 80% of nominal
bandwidth.
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
12 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
