Tektronix DSA70000D Series Technical Reference

MSO/DPO70804C, MSO/
DPO70604C, MSO/DPO70404C
Step settings Temperature constraint
± 0.5 dB from DC to 50% of nominal bandwidth.
± 1 dB from 50% to 80% of nominal bandwidth.
10 °C to 40 °C
Typical temperature variation
Frequency TC, (dB/°C)
DC – 11 GHz
12.5 GHz
16 GHz
18 GHz
20 GHz
0
– 0.02
– 0.04
– 0.09
– 0.09
Calculated rise time 50 Ω, typical,
>20 GHz models
DSP On DSP Off
10% - 90% 20% - 80% 10% - 90% 20% - 80%
MSO/DPO73304DX 13 ps 9 ps 21 ps 14 ps
MSO/DPO72504DX 16 ps 12 ps 22 ps 15 ps
MSO/DPO72304DX 17 ps 13 ps 24 ps 16 ps
Calculated rise time 50 Ω, typical,
≥4 GHz ≤20 GHz models
DSP On DSP Off
10% - 90% 20% - 80% 10% - 90% 20% - 80%
MSO/DPO72004C at 20 GHz 19 ps 14 ps NA NA
MSO/DPO72004C at 18 GHz 22 ps 15 ps NA NA
MSO/DPO71604C 24.5 ps 17 ps 30 ps 20 ps
MSO/DPO71254C 32 ps 22 ps 33 ps 23 ps
MSO/DPO70804C 49 ps 34 ps 47 ps 32 ps
MSO/DPO70604C 65 ps 45 ps 62 ps 43 ps
MSO/DPO70404C 98 ps 68 ps 93 ps 65 ps
Calculated rise time 50 Ω, typical,
<4 GHz models
DPO7354C
Scale 10% - 90%
1 mV/div - 1.99 mV/div 1.2 ns
2 mV/div - 4.99 mV/div 650 ps
5 mV/div - 9.9 mV/div 180 ps
10 mV/div - 1 V/div, BWE off 145 ps
10 mV/div - 1 V/div, BWE on 115 ps (signals limited to 4 vertical divisions)
DPO7254C
Scale 10% - 90%
1 mV/div - 1.99 mV/div 1.2 ns
2 mV/div - 4.99 mV/div 650 ps
5 mV/div - 9.9 mV/div 180 ps
10 mV/div - 1 V/div 160 ps
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 13
