Tektronix DSA70000D Series Technical Reference

Enhanced bandwidth
MSO/DPO72004C MSO/DPO71604C MSO/DPO71254C
Input
frequency
50 GS/s 100 GS/s 50 GS/s 100 GS/s 50 GS/s 100 GS/s
10 MHz 5.0 bits 5.3 bits 5.6 bits 6.0 bits 5.9 bits 6.2 bits
1 GHz 5.0 bits 5.3 bits 5.6 bits 5.9 bits 5.8 bits 6.1 bits
2 GHz 4.9 bits 5.2 bits 5.6 bits 5.9 bits 5.7 bits 5.9 bits
3 GHz 4.9 bits 5.0 bits 4.6 bits 4.4 bits 4.8 bits 4.5 bits
4 GHz 4.8 bits 4.9 bits 4.2 bits 4.0 bits 4.3 bits 4.0 bits
5 GHz 4.8 bits 4.9 bits 4.6 bits 4.4 bits 5.5 bits 5.2 bits
6 GHz 4.7 bits 4.8 bits 4.5 bits 4.3 bits 4.9 bits 4.8 bits
7 GHz 4.0 bits 3.97 bits 3.9 bits 3.7 bits 5.5 bits 5.6 bits
8 GHz 3.6 bits 3.9 bits 3.4 bits 3.5 bits 5.6 bits 5.8 bits
9 GHz 3.2 bits 3.2 bits 5.1 bits 5.1 bits 5.6 bits 5.8 bits
10 GHz 2.8 bits 2.8 bits 5.5 bits 5.7 bits 5.6 bits 5.8 bits
11 GHz 3.9 bits 3.9 bits 5.4 bits 5.6 bits 5.6 bits 5.8 bits
12 GHz 4.8 bits 5.0 bits 5.4 bits 5.6 bits 5.6 bits 5.7 bits
13 GHz 4.5 bits 4.7 bits 5.2 bits 5.4 bits
14 GHz 4.4 bits 4.6 bits 5.1 bits 5.3 bits
15 GHz 4.5 bits 4.7 bits 5.1 bits 5.0 bits
16 GHz 4.5 bits 4.7 bits 4.8 bits 5.0 bits
17 GHz 4.1 bits 4.6 bits
18 GHz 4.2 bits 4.7 bits
19 GHz 4.6 bits 4.8 bits
20 GHz 4.8 bits 5.0 bits
Enhanced bandwidth
MSO/DPO70804C MSO/DPO70604C MSO/DPO70404C
Input frequency 25 GS/s 25 GS/s 25 GS/s
10 MHz 5.7 bits 5.8 bits 6.0 bits
1 GHz 5.7 bits 5.8 bits 5.9 bits
2 GHz 5.7 bits 5.7 bits 5.8 bits
3 GHz 5.5 bits 5.6 bits 5.7 bits
4 GHz 5.5 bits 5.6 bits 5.7 bits
5 GHz 5.5 bits 5.5 bits
6 GHz 5.4 bits 5.4 bits
7 GHz 5.4 bits
8 GHz 5.3 bits
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 19

Tektronix DSA70000D Series Specifications

General

Brand	Tektronix
Model	DSA70000D Series
Category	Test Equipment
Language	English
