Tektronix DSA70000D Series Technical Reference

Without enhanced bandwidth
MSO/DPO73304DX MSO/DPO72504DX MSO/DPO72304DX
Input
frequency
50 GS/s 100 GS/s 50 GS/s 100 GS/s 50 GS/s 100 GS/s
10 MHz 5.2 bits 5.2 bits 5.2 bits 5.2 bits 5.2 bits 5.4 bits
1 GHz 4.8 bits 4.8 bits 5.0 bits 5.0 bits 5.0 bits 5.0 bits
2 GHz 4.9 bits 4.9 bits 5.0 bits 5.0 bits 5.0 bits 5.1 bits
3 GHz 4.8 bits 4.8 bits 4.9 bits 4.9 bits 4.9 bits 5.1 bits
4 GHz 4.7 bits 4.7 bits 4.5 bits 4.7 bits 4.7 bits 4.7 bits
5 GHz 4.7 bits 4.7 bits 4.7 bits 4.7 bits 4.7 bits 4.8 bits
6 GHz 4.7 bits 4.7 bits 4.7 bits 4.7 bits 4.7 bits 4.8 bits
7 GHz 4.7 bits 4.7 bits 4.7 bits 4.7 bits 4.7 bits 4.9 bits
8 GHz 4.6 bits 4.6 bits 4.8 bits 4.8 bits 4.7 bits 4.9 bits
9 GHz 4.7 bits 4.6 bits 4.7 bits 4.7 bits 4.7 bits 4.9 bits
10 GHz 4.7 bits 4.7 bits 4.7 bits 4.7 bits 4.7 bits 4.9 bits
11 GHz 4.7 bits 4.7 bits 4.7 bits 4.7 bits 4.7 bits 4.9 bits
12 GHz 4.7 bits 4.7 bits 4.7 bits 4.7 bits 4.7 bits 4.9 bits
13 GHz 4.5 bits 4.5 bits 4.5 bits 4.5 bits 4.5 bits 4.8 bits
14 GHz 4.7 bits 4.7 bits 4.7 bits 4.7 bits 4.7 bits 4.9 bits
15 GHz 4.6 bits 4.6 bits 4.6 bits 4.6 bits 4.6 bits 4.7 bits
16 GHz 4.5 bits 4.4 bits 4.5 bits 4.4 bits 4.5 bits 4.7 bits
17 GHz 4.5 bits 4.4 bits 4.5 bits 4.4 bits 4.5 bits 4.7 bits
18 GHz 4.5 bits 4.4 bits 4.5 bits 4.4 bits 4.5 bits 4.6 bits
19 GHz 4.2 bits 4.1 bits 4.5 bits 4.4 bits 4.5 bits 4.5 bits
20 GHz 4.3 bits 4.2 bits 4.5 bits 4.5 bits 4.5 bits 4.5 bits
21 GHz 4.5 bits 4.5 bits 4.6 bits 4.6 bits 4.5 bits 4.6 bits
22 GHz 4.5 bits 4.4 bits 4.6 bits 4.6 bits 4.5 bits 4.8 bits
23 GHz 4.5 bits 4.4 bits 4.6 bits 4.6 bits 4.3 bits 4.8 bits
24 GHz 4.4 bits 4.5 bits 4.6 bits 4.6 bits
25 GHz 4.5 bits 4.4 bits 4.5 bits 4.5 bits
26GHz 4.4 bits 4.3 bits
27 GHz 4.1 bits 4.34 bits
28 GHz 4.1 bits 4.1 bits
29 GHz 4.2 bits 3.8 bits
30 GHz 4.2 bits 4.2 bits
31 GHz 4.4 bits 4.2 bits
32 GHz 4.1 bits 4.1 bits
33 GHz 4.3 bits 4.2 bits
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
20 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series

Tektronix DSA70000D Series Specifications
