Model 7700 Multiplexer Module Instructions for use with DAQ6510
14 077144300 / April 2018
Recommended test equipment
The table below summarizes recommended verification equipment. You can use alternate equipment if that
equipment has specifications if that equipment has specifications that meet or exceed those listed below. Be
aware that calibrator uncertainty adds to the uncertainty of each measurement.
Fluke 5700A Calibrator:
DC voltage AC voltage (1 kHz, 50 kHz) Resistance
100 mV: ±14 ppm 100 mV: ±200 ppm 100 Ω: ±17 ppm
1.0 V: ±7 ppm 1.0 V: ±82 ppm 1 kΩ: ±12 ppm
10 V: ±5 ppm 10 V: ±82 ppm 10 kΩ: ±11 ppm
100 V: ±7 ppm 100 V: ±90 ppm 100 kΩ: ±13 ppm
1000 V: ±9 ppm 700 V: ±85 ppm 1 MΩ: ±18 ppm
10 MΩ: ±37 ppm
100 MΩ: ±120 ppm
Fluke 5725A Amplifier
AC Voltage, 50 kHz: 700 V, ±375 ppm
The Fluke 5725A amplifier is necessary only if you need to verify the 750 VAC range at 50 kHz.
Verification at 220 V and 50 kHz using the 5700A calibrator is adequate for most applications.
Keithley 3930A or 3940 Frequency Synthesizer
1 V
RMS
, 10 V
RMS
, 1 kHz, ±5 ppm, steady state and burst modulation
General Radio 1433-T Precision Decade Resistance Box
10 Ω to 400 Ω, ±0.02%
Miscellaneous equipment
Double banana plug to double banana plug shielded cables (two)
BNC to double banana plug shielded cable
