Tektronix MDO3104

Save and Recall I
nformation
USB
Device
Port
Connect to
Computer
5. Push Connect to PictBridge Printer.
Connect to
PictBridge
Printer
Disabled
(Off bus)
Printing Ov
er Ethernet
To set up the oscilloscope to print over Ethernet:
1. Connect an Ethernet cable to the rear-panel
Ethernet port.
2. Push Utility.
3. Push Utility Page.
Utility
Page
4. Turn the Mu ltipurpose a knob and select
Prin
t Setup.
Print
Setu
p
MDO3000 Series Oscilloscopes User Manual 175
