Acquire the Signal
Then, turn multipurpose knob b to define the
voltage level above which the oscilloscope
treats the signal as a logic high and below
which as a logic low.
5. Push B1 Label to edit the label fo r the bus.
(See page 84, Labeling Channels and Buse s.)
Bus
Parallel
Define
Inputs
Thresholds B1 Label
Parallel
Bus Display Event Table
106 MSO4000 and DPO4000 Series Oscilloscopes User Manual
