Installation
Optional Accessories (cont.)
Accessory Description Tektronix part number
DPO4AUTOMAX The FlexRay, CAN, and LIN serial triggering and
analysis module provides FlexRay bus support
as well as all the features of the DPO4AUTO
module (CAN and LIN bus support).
NOTE. LIN and FlexRa y work on DPO4000 s
with serial numbers greater than C020000 and
on all MSO4000s. Oscilloscopes purchased
under GSA contract may use a different serial
number scheme. Contact Tektronix if you need
more d etails.
DPO4AUTOMAX
DPO4COMP
The compute r triggering and analysis module
enables triggering on RS-232, RS-422 , R S-485
and UART serial buses, search tools, bus views,
bus decoding in hex, binary, and ASCII, and
decode tables with timestamp information
DPO4COMP
DPO4VID
The extended video module enables triggering
on a variety of standard HDTV signals, as well
as on custom (non-standard) bilevel a nd trilevel
video signals with 3 to 4,000 lines.
DPO4VID
DPO4AUDIO
The audio serial triggering and analysis module
enables triggering on I
2
S, Left Justified (LJ), Right
Justified (RJ), and TDM buses.
DPO4AUDIO
MSO4000 and DPO4000 Series Oscilloscopes User Manual 5
