Get Acquainted with the Instrument
2. The trigger p osition icon shows the trigger
position in the acquisition.
3. The expansion point icon (an orange
triangle) shows the point that the horizontal
scale expands and compresses around.
4. The waveform record view shows the
trigger location relative to the waveform
record. The line color corresponds to the
selected waveform color.
70 MSO4000 and DPO4000 S eries Oscilloscopes User Manual
