Analyze Waveform Data
2. Push Add Measurement .
Add Mea-
surement
Remove
Measure-
ment
Indicators
Gating
Screen
High-Low
Method
Auto
Bring
Cursors On
Screen
Configure
Cursors
3. Turn multipurpose knob a to select the
Measurement Type of Snapshot All.
4. Push OK Snapshot All Meas.
OK
Snapshot
All Meas
5. View results.
