Acquire the Sign
al
5. Push Bit Rate a
nd turn multipurpose knob a
to select from the list of predefined bit rates.
Bus
FlexRay
Define
Inputs
Thresholds
786mV
22.00 V
Bit Rate
1000000
B1 Label
FlexRay
Bus
Display
Event
Table
Alternately,
you can set the bit rate to a
specific value. To do so, select Custom, and
then turn multipurpose knob b to set the bit
rate from 1,0
00,000 to 10,000,000 b/s.
Audio Bus
To acquire data from an audio bus, you need to also set up these items:
1. If you selected Audio, push Defi ne Input
and the desired side menu choices.
Bus
Audio
Define
Inputs
Thresholds
Configure
B1 Label
RS-232
Bus
Display
Event
Table
