Giving Demos of M SO400 0 Features
4. Push Acquire.
5. Push the lower-bezel menu Record Length
button (if not already active) and the side-bezel
menu 1M points button.
Mode
Sample
Record
Length
1M
Reset
Horizontal
Position
Waveform
Display
6. Push D15–D0
98 Tektronix 4000 Oscilloscope Demo Instruction Manual
