Giving Demos of Advanced Tektronix 40 00 Features
23. Turn multipurpose knobs a and b to enter a
hex addre s s of 50.
While doing this, notice the pre-p rogra mmed
addresses.
24. Push the lower-bezel Direction button.
I2C
Direction
Read
Write
25. Select the side-bezel Write button.
Read or
Write
48 Tektronix 4000 Oscilloscope Demo Instruction Manual
