Giving Demos of Advanced Tektronix 40 00 Features
18. Push the lower-bezel Event Table.
Event Table
19. Push the side-bezel Event Table button to
select On.
Event Table
On|Off
The event table presents information in an
alternative w ay to the graphical bus waveform
display. It resembles a state listing window in
a logic analyzer.
Notice that you can now view ea ch character
in the listing display.
20. Turn off the event ta ble.
62 Tektronix 4000 Oscilloscope Demo Instruction Manual
