Tektronix MSO44 User Manual

Table 6: Rear case
Index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont'd
Qty Name & description
Figure 3 on page
34
-1 211-1688-XX 4 SCREW, MACHINE, M3X0.5X10, FLAT HEAD 90 DEG, SUS410
NYLOK, TORX T10
-2 050-3905-XX 1 MODULE ASSY:SERVICE REPLACEMENT KIT, HANDLE METAL
BASE W/PLASTIC GRIP AND HARDWARE, MSO4 SERIES
-3 211-1636-XX 4
SCREW, MACHINE, M3x0.5x8MM PAN HEAD, TORX T10 WITH
NYLON PATCH
-4 065-1058-XX 1 MODULE ASSY:SERVICE REPLACEMENT KIT;HANDLE HUB
LEFT AND RIGHT (SET), MSO4 SERIES
-5
378-0961-XX 1 GRILL, COSMETIC, REAR, MSO4K SERIES, SAFETY
CONTROLLED
-6
211-1686-XX 12 SCREW, MACHINE; M3X0.5X10, FLAT HEAD, STL, TORX 10
-7 065-1047-XX 2 MODULE ASSY:SERVICE REPLACEMENT KIT;REAR FLIP FEET,
MSO4 SERIES
-8 202-0567-XX 1 CASE, REAR, MSO4K SERIES, SAFETY CONTROLLED
Replaceable parts
4 Series MSO (MSO44, MSO46) Service 35

Tektronix MSO44 Specifications

General

Bandwidth	200 MHz, 350 MHz, 500 MHz, 1 GHz
Analog Channels	4
Operating Temperature	0 °C to +50 °C
Sample Rate	6.25 GS/s
Record Length	62.5 Mpoints
Input Impedance	1 MΩ ±1%, 50 Ω ±1%
Vertical Resolution	12 bits
Waveform Capture Rate	Up to 500, 000 wfm/s
Maximum Input Voltage	5 VRMS (50 Ω)
Probe Interface	TekVPI
Digital Channels	16 (optional)
