Tektronix MSO44 User Manual

Table 7: Front assembly
Fig. &
index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont'd
Qty Name & description
Figure 4 on page
36
-1 065-1052-XX 1
MODULE ASSY:SERVICE REPLACEMENT KIT;DISPLAY/TOUCH
SCREEN ASSY
Return the instrument to Tektronix for service.
-2 065-1056-XX 1
MODULE ASSY:SERVICE REPLACEMENT KIT;6CH FRONT
CASE WITH LABELS
MSO46
065-1055-XX 1 MODULE ASSY:SERVICE REPLACEMENT KIT;4CH FRONT
CASE WITH LABELS
MSO44
-3 211-1584-XX 4 SCREW, MACHINE, M3X0.5X6 MM PAN HEAD, TORX T10
-4 366-0945-XX 1 ASSEMBLY, KNOB, LARGE WITH OVERMOLD
-5 366-0943-XX 1 ASSEMBLY, KNOB, SMALL WITH OVERMOLD
-6 366-0946-XX 1 ASSEMBLY, KNOB, PAN WITH OVERMOLD
-7 358-0890-XX 1 BUSHING, SPACER, RING JOG-SHUTTLE
-8 366-0947-XX 1 ASSEMBLY, KNOB, ZOOM WITH OVERMOLD
-9 366-0944-XX
1
ASSEMBLY, KNOB, MEDIUM WITH OVERMOLD
Replaceable parts
4 Series MSO (MSO44, MSO46) Service 37

Tektronix MSO44 Specifications

General

Bandwidth	200 MHz, 350 MHz, 500 MHz, 1 GHz
Analog Channels	4
Operating Temperature	0 °C to +50 °C
Sample Rate	6.25 GS/s
Record Length	62.5 Mpoints
Input Impedance	1 MΩ ±1%, 50 Ω ±1%
Vertical Resolution	12 bits
Waveform Capture Rate	Up to 500, 000 wfm/s
Maximum Input Voltage	5 VRMS (50 Ω)
Probe Interface	TekVPI
Digital Channels	16 (optional)
