Fig. &
index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont'd
Qty Name & description
-1 441-2901-XX 1
CHASSIS, FRONT, ASSEMBLY
Return the instrument to T
ektronix for service.
-2 878-1383-XX 1
CIRCUIT BOARD ASSY, PROCESSOR, 878-1383-XX TESTED
WITH PACKAGING
Return the instrument to Tektronix for service.
-3 878-1376-XX 1
CIRCUIT BOARD ASSY, 6CH MAIN, 389-5345-XX, BOMBLD STD
Return the instrument to Tektronix for service.
MSO46
878-1593-XX 1 CIRCUIT BOARD ASSY, 4CH MAIN, 878-1593-XX TESTED WITH
PACKAGING
Return the instrument to Tektronix for service.
MSO44
-4 211-1584-XX 10 SCREW, MACHINE, M3X0.5X6 MM PAN HEAD, TORX T10
Replaceable parts
4 Series MSO (MSO44, MSO46) Service 43

Tektronix MSO44 Specifications

General

Bandwidth	200 MHz, 350 MHz, 500 MHz, 1 GHz
Analog Channels	4
Operating Temperature	0 °C to +50 °C
Sample Rate	6.25 GS/s
Record Length	62.5 Mpoints
Input Impedance	1 MΩ ±1%, 50 Ω ±1%
Vertical Resolution	12 bits
Waveform Capture Rate	Up to 500, 000 wfm/s
Maximum Input Voltage	5 VRMS (50 Ω)
Probe Interface	TekVPI
Digital Channels	16 (optional)
