Tektronix MSO54 Printable Help

Rise/Fall Time Search configuration menu fields and controls.
Field or control Description
Display Sets the display of the mark icons on or off. If you have multiple searches defined, the control
turns off just the marks for the selected search.
Stop Acquisition if Event
Found
Stops input acquisition when the search event occurs. Default is not enabled.
Search Type Set to Rise/Fall Time.
Source Lists the source channel or waveform to use to trigger or search. Types that require multiple
inputs will replace this control with a different source definition control.
Mark When
■
< Limit: A signal has a rise time less than the specified time limit.
■
> Limit: A signal has a rise time greater than the specified time limit.
■
= Limit: A signal has a rise time that is equal to the specified time limit (±5%).
■
≠ Limit: A signal has a rise time that does not equal (is greater than or less than) the
specified time limit (±5%).
Time Limit Sets the time period condition to be met.
Slope Sets the signal transition direction to detect. (rising, falling, or either direction).
Upper Threshold Sets the upper threshold amplitude level through which the signal must pass to be considered a
valid transition.
Lower Threshold Sets the lower threshold amplitude level through which the signal must pass to be considered a
valid transition.
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
Other search types.
Bus Search configuration menus on page 230
Edge Search configuration menu on page 250
Logic search configuration menu on page 251
Pulse Width Search configuration menu on page 253
Runt Search configuration menu on page 257
Setup and Hold Search configuration menu on page 258
Timeout Search configuration menu on page 260
Window Search configuration menu on page 262
Menus and dialog boxes
256 MSO54, MSO56, MSO58, MSO58LP, MSO64 Help
