A Trigger Event configuration menu
Use this menu to set the trigger conditions for the A trigger event of a Sequence trigger.
To open the A Trigger Event menu:
1. Double-tap the Trigger badge on the Settings bar.
2. Set the Trigger Type to Sequence.
3. Tap the A Trigger Event button.
A Trigger Event menu (Sequence Trigger configuration menu) fields and controls.
Field or control Description
Trigger Type Select the A event trigger type.
Other fields and controls The fields and controls shown depend on the selected Trigger Type. Use the following links to
access setting information on a specific trigger.
■
Bus Trigger Menu
■
Edge Trigger menu
■
Logic Trigger
■
Pulse Width Trigger menu
■
Rise/Fall Time Trigger menu
■
Runt Trigger menu
■
Sequence Trigger menu
■
Setup & Hold Trigger menu
■
Timeout Trigger menu
■
Window Trigger menu
NOTE. The Sequence Trigger type is not available in the A Trigger Event menu.
B Trigger Event configuration menu
Use this menu to set the trigger conditions for the B trigger event of a Sequence trigger.
To open the B-Trigger Event configuration menu:
1. Double-tap the Trigger badge on the Settings bar.
2. Set the Trigger Type to Sequence.
3. Tap the B Trigger Event button.
