Common badge actions

Action Result Example

Single tap Immediate access controls (Scale,

Navigation).

Double tap Configuration menu with access to

all settings for the badge.

Touch and hold Right-click menu with single tap

access to common actions. Typical

actions include turning off a

channel and deleting a

measurement or search badge.
