Tektronix MSO58 Service Manual

Index
number
Tektronix part
number
Serial no. effective Qty Name & description
-XXX 131-6417-XX 5 CONTACT, ELECTRICAL (GROUNDING)
Return the instrument to T
ektronix for service.
-13 870-1198-XX - CIRCUIT BD ASSY; CIRCUIT BOARD SUBASSY; 2GHZ ANALOG
BOARD; 389499900; TESTED
Return the instrument to Tektronix for service.
2 4 channel quantity
3 6 channel quantity
4 8 channel quantity
870-1039-XX - CIRCUIT BD ASSY; CIRCUIT BOARD SUBASSY; 350MHz-1GHz
ANALOG BOARD; 389482700; TESTED
Return the instrument to Tektronix for service.
2 4 channel quantity
3 6 channel quantity
4 8 channel quantity
-14 253-0560-XX - THERMAL INTERFACE MATERIAL
Return the instrument to Tektronix for service.
Applies to models with 2GHz boards only. If Thermal Interface
Material is removed during service replace it during reassembly.
4 4 channel quantity
6 6 channel quantity
8 8 channel quantity
-15 131-9410-XX 1 CONNECTOR, RECEPTACLE, GROUND JACK
Return the instrument to Tektronix for service.
-16 380-1277-XX 1 HOUSING, PROBE COMP
Return the instrument to Tektronix for service.
-17 878-1145-XX 1 CIRCUIT BOARD SUBASSY; FRONT PANEL ENCODER BOARD,
UNTESTED, 389493700
Return the instrument to Tektronix for service.
-18 361-1873-XX 1 SPACER, FRONT PANEL, SAFETY CONTROLLED
Return the instrument to Tektronix for service.
Table continued…
Replaceable parts
5 Series MSO Service Manual MSO54, MSO56, MSO58 48
