Set the display size of logic channels

NOTE. The Display Size of Logic Channels option is available only on MSO5000B and MSO70000C/DX Series instruments and

DPO5000B Series instruments with option MSOE installed, and DPO70000DX instruments with option MSOU installed.

From the Digital menu, select Digital Setup and use the Size selection box to define the height of the digital channel in the

display.

To use

■

Click Size and select from the drop-down list: Large, Medium, Small, and Extra Small.

Behavior

■

Large displays the channel as a division.

■

Medium displays the channel as half a division.

■

Small displays the channel as a quarter of a division.

■

Extra Small displays the channel as a fifth of a division.

What do you want to do next?

Learn about setting up digital signals.

Learn more about digital setups.

Learn about bus setups.

Learn about bus configuration.

Set the global threshold for digital channels

NOTE. The Global Threshold for Digital Channels option is available only on MSO5000B and MSO70000C/DX Series

instruments and DPO5000B Series instruments with option MSOE installed, and DPO70000DX instruments with option MSOU

installed.

From the Digital menu, select Digital Setup and use the Global Threshold entry box to define the same voltage threshold level for

all digital channels.

Digital setups

104 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
