To use.

1. Select the Palette for the image:

■

Color

■

Color (Ink Saver Mode)

■

Black & White

2. Select the type of View:

■

Full Screen. Copies an image of the entire screen.

■

Graticule(s) Only. Copies an image of the selected graticule.

3. Click the Hide Menu/Toolbar check box to save the image without including the Menu bar or Toolbar.

4. Click OK.

Behavior. The Palette, View, and Image selections are identical to those in the Page Setup dialog box and in the Screen

Capture Save Options dialog box.

The copy operation takes place after you click Copy. Clicking OK saves the changes and closes the dialog box but does not copy

the image.

NOTE. Bitmap (.bmp) is the only available Data Format.

What do you want to do next?

Learn about copying waveforms.

Learn about copying measurements.

Learn about saving images to a file.

Copy setup (Waveforms)

From the Edit menu, select Copy Setup; then open the Waveforms tab.

Copying and printing

518 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
