To use. Click a control to insert time domain functions into the math expression.

1. Click one of the Primitive buttons to insert a Time function into the math expression.

Primitive buttons

Average Sqrt FABS Sin Cos Tan

Integral Log 10 Ceil ASin ACos ATan

Derivative Log e Floor Sinh Cosh Tanh

Invert Exp Min Max WfmDB

2. Click More to add additional functions.

Math setups

262 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
