Behavior

This dialog box opens when you click Export from the Select the columns to Copy/Export dialog box. The default file type is a file

with comma separated values (.csv).

The default folder is C:\Users\[Username]\Tektronix\TekScope\data.

NOTE. Any characters that you enter in the file name box become part of the file name. The instrument does not use any user-

defined file extensions.

What do you want to do next?

Learn about selecting the columns to Copy/Export.

Analyzing waveforms
