Demo 3: Traces and detectors
This demo familiarizes you with the trace detection and function controls available in SignalVu-PC used with the
RSA306.
Instructions for the demo board
1. Keep the same setting (OFDM signal)
as the last demo.
Demo3OFDM
1
Instructions for the RSA306
1. Keep the same setting, or recall the
setting Demo2_OFDM_marker.tiq.
Click Run.
Demo3Step1
1
Demo instructions
