Demo 5: DPX and transient capture
The DPX display helps you to see how traces change over time and displays signal events that cannot be seen on a
swept spectrum analyzer. DPX Spectrum indicates how traces change in two ways. First, it uses color shading to
show how consistent the shape of a trace is. Second, it uses persistence to hold signals on the screen so you can
see them longer. The DPX display reveals transient signal behavior that helps you discover instability, glitches, and
interference.
Instructions for the demo board
1. Keep the same setting as the last
demo. Use the ROW and COLUMN
buttons to change the signal from
OFDM to Inf Hop (Infrequent hopping
signals).
