4. In the Traces tab, select Trace 1, and
then set Detection to Avg (VRMS)
and Function to Avg (VRMS).
Demo3Step4
4
5. Select Trace 2, and then set
Detection to +Peak, Function to Max
Hold, and enable Show.
Demo3Step5
5
Demo instructions
RSA306 Self-Guided Demo 31
