TIP. Symbol table
Each symbol value is assigned a position in the Constellation diagram. The Symbol Table will be used to
demonstrate the mapping between quadrants in the Constellation diagram and the symbol values.
TIP. Correlated display
Not only are all the displays correlated through the shared data set, but the markers, which are inherently
correlated, make it very easy to see how a data point in one domain relates to a specific data point in any
other. This can greatly reduce troubleshooting time.
Demo instructions
74 RSA306 Self-Guided Demo
