Tektronix RSA5100B Series Technical Reference

Specifications
Table 17: Pulse measurements, typical (cont.)
Characteristic Description
Pulse-to-Pulse carrier phase, Linear-Chirped
Pulse, typical
60 MHz BW
5
25 MHz BW
6
2 GHz ±0.3° ±0.25°
10 GHz ±0.5° ±0.5°
20 GHz ±0.8° ±0.8°
85 MHz BW
5
40 MHz BW
6
2 GHz ±0.3° ±0.25°
10 GHz ±0.5° ±0.5°
20 GHz ±0.8° ±0.8°
125 MHz BW
5
2GHz ±0.3°
10 GHz ±0.5°
20 GHz ±0.8°
160 MHz BW
5
2GHz ±0.3°
10 GHz ±0.5°
20 GHz ±0.8°
Pulse-to-Pulse carrier Frequency,
NON-Chirped Pulse, typical
60 MHz BW
7
25 MHz BW
8
2GHz
±50 kHz ±15 kHz
10 GHz
±75 kHz ±20 kHz
20 GHz
±100 kHz ±25 kHz
85 MHz BW
7
40 MHz BW
8
2GHz
±100 kHz ±20 kHz
10 GHz
±125 kHz ±30 kHz
20 GHz
±175 kHz ±40 kHz
125 MHz BW
7
2GHz
±100 kHz
10 GHz
±125 kHz
20 GHz
±175 kHz
160 MHz BW
7
2GHz
±100 kHz
10 GHz
±125 kHz
20 GHz
±175 kHz
RSA5100B Series Technical Reference 19
