Tektronix RSA5100B Series

Specifications
Table 17: Pulse measurements, typical (cont.)
Characteristic Description
Pulse-to-Pulse carrier Frequency,
Linear-Chirped Pulse, typical
60 MHz BW
9
25 MHz BW
10
2GHz
±125 kHz ±15 kHz
10 GHz
±150 kHz ±20 kHz
20 GHz
±150 kHz ±25 kHz
85 MHz BW
9
110 MHz BW
10
2GHz
±125 kHz ±20 kHz
10 GHz
±150 kHz ±30 kHz
20 GHz
±175 kHz ±50 kHz
125, 160 MHz BW
9
2GHz
±125 kHz
10 GHz
±150 kHz
20 GHz
±200 kHz
Pulse Frequency Linearity (Absolute
Frequency Error RMS)
60 MHz BW
11
25 MHz BW
12
2GHz
±8 kHz ±2.5 kHz
10 GHz
±15 kHz ±2.5 kHz
20 GHz
±20 kHz ±3.5 kHz
85 MHz BW
11
40 MHz
12
2GHz
±15 kHz ±3.5 kHz
10 GHz
±20 kHz ±5 kHz
20 GHz
±25 kHz ±7.5 kHz
125 MHz BW
11
2GHz
±20 kHz
10 GHz
±25 kHz
20 GHz
±40 kHz
160 MHz BW
11
2GHz
±20 kHz
10 GHz
±25 kHz
20 GHz
±40 kHz
20 RSA5100B Series Technical Reference
