Tektronix RSA5100B Series

Specifications
Table 17: Pulse measurements, typical (cont.)
Characteristic Description
Chirp Frequency Linearity
(Absolute Frequency Error RMS)
60 MHz BW
13
20 MHz BW
14
2GHz
±25 kHz ±3 kHz
10 GHz
±30 kHz ±3 kHz
20 GHz
±30 kHz ±5 kHz
85 MHz BW
13
25 and 40 MHz BW
14
2GHz
±25 kHz ±5 kHz
10 GHz
±30 kHz ±8 kHz
20 GHz
±30 kHz ±10 kHz
125, 160 MHz BW
13
2GHz
±35 kHz
10 GHz
±40 kHz
20 GHz
±40 kHz
1
For conditions of:
CW (non-chirped) pulses
Frequency Estimation = Manual
Pulse ON power  –20 dBm
Signal peak at Ref Lvl.
Atten=0dB
Pulse width  200 ns.
PRI 300 us.
Duty cycle  0.0007
t
meas
–t
reference
 10 ms
Measurement time position excludes the beginning and ending of the pulse extending for a time = (10/measurem ent Bandwidth) as measured from the
50% point of the Tr or Tf.
2
For conditions of:
CW (non-chirped) pulses
Frequency Estimation = Manual
Pulse ON power  –20 dBm
Signal peak at Ref Lvl.
Atten=0dB
Pulse width  300 ns.
PRI 300 us
.
Duty cycle  0.001
t
meas
–t
reference
 10 ms
Measurement time position excludes the beginning and ending of the pulse extending for a time = (10/measurem ent Bandwidth) as measured from the
50% point of the Tr or Tf.
3
CW (non-chirped) pulses
Frequency Estimation = Manual
Pulse ON power  –20 dBm
Signal peak at Ref Lvl.
Atten=0dB
Pulse width  1 s.
PRI 300 us.
RSA5100B Series Technical Reference 21
