TAS 200 Series Adjustment Procedures
Bench Test Instruments and Handheld Oscilloscopes Basic Service
25
Rear panel mounting
screws (4)
Rear
panel
Instrument
cover
Cover
screws (2)
Figure 6: TAS 220 and TAS 250 instrument cover removal
