Tektronix TBS1000C Series

Table 4: Adjustment steps
Input Setup diagram Step number Signal Signal source setting
Ch 1 through Ch 2 DC voltage 1 1 DC Voltage 1 0.0 V
2 DC Voltage 1 -20.0 V
3 DC Voltage 1 -2.0 V
4 DC Voltage 1 -1.6 V
5 DC Voltage 1 -1.2 V
6 DC Voltage 1 -0.8 V
7 DC Voltage 1 -0.4 V
8 DC Voltage 1 -0.32 V
9 DC Voltage 1 -0.2 V
10 DC Voltage 1 -0.16 V
11 DC Voltage 1 -0.08 V
12 DC Voltage 1 -0.04 V
13 DC Voltage 1 -0.03 V
14 DC Voltage 1 -0.02 V
15 DC Voltage 1 -0.015 V
16 DC Voltage 1 0.015 V
17 DC Voltage 1 0.02 V
18 DC Voltage 1 0.03 V
19 DC Voltage 1 0.04 V
20 DC Voltage 1 0.08 V
21 DC Voltage 1 0.16 V
22 DC Voltage 1 0.2 V
23 DC Voltage 1 0.32 V
24 DC Voltage 1 0.4 V
25 DC Voltage 1 0.8 V
26 DC Voltage 1 1.2 V
27 DC Voltage 1 1.6 V
28 DC Voltage 1 2.0 V
29 DC Voltage 1 20.0 V
30 DC Voltage 1 0.0 V
Ext Trig DC voltage 2 31 DC Voltage 2 -5.0 V
32 DC Voltage 2 -1.0 V
33 DC Voltage 2 1.0 V
34 DC Voltage 2 5.0 V
Adjustments
TBS1000C Series Oscilloscope Service Manual 13
