Application Notes
Application Notes
This section describes some of the typical measurement applications of the
TCPA300 and TCPA400 Current Probe Amplifiers:
Automobile Charging Systems
Inductance Measurements
Continuity Test of Multiple-Conductor Cable
Measuring Inductor Turns Count
Power Mea
surement and Analysis Software Applications
Automobile Charging Systems
Most aut
omotive c harging s ystems are three-phase alternators with a diode
rectifier network. A meter averages current from all three phases, and c annot
detect a single-phase diode problem. Observing the charge current waveform can
quickly reveal if one diode is shorted or open. (See Figure 19 on page 34.)
A TCP303 Current Probe was used for this high-current, low-voltage application.
The TCP303 is degaussed and clamped around the p ositive battery lead from the
alternator. (See Figure 18.) The probe arrow is pointed away from the alternator
and toward the battery side of the circuit, to reflect conventional current. The
auto
mobile is started and the lights are turned on to add a significant load to the
circuit.
Table 4: Automobile charging systems test setup
Instrument Control Setting
TCPA300 COUPLING DC
RANGE 50 A/V
Oscilloscope Coupling DC
Amps/Division
(Volts/Division if not using
TEKPROBE interface cable)
10 A/Div (200 mV/Div)
Zero-Current Reference Center graticule line
Time Base
200 ms/division
TCPA300/400 Amplifiers and TCP300/400 Series Current Probes User Manual 33
