Tektronix TCP300 Series User Manual

Specifications
Table 10: Probe
mechanical characteristics
TCP305 and TCP312 TCP303 and TCP404XL
Probe dimensi
ons
Length:
20 cm (7.77 in
ches)
268 mm (10.55
inches)
Width:
1.6 cm (0.62
5 inches)
41 mm (1.60 i
nches)
Height:
3.2 cm (1.25
inches)
68 mm (2.7 in
ches)
Cable leng
th
1.5 m (5 fee
t)
TCP303: 2 m
(6.6 feet)
TCP404XL: 8 m (26.25 feet)
Weight
0.15 kg (0.33 lb) TCP303: 0.66 kg (1.45 lb)
TCP404XL: 0.88 kg (1.90 lb)
Figur
e 27: Probe jaw dimensions (nominal)
Table 11: Shipping weights and dimensions
TCPA300 and
TCPA
400 Amplifiers
TCP3
05 and TCP 312
TCP3
03
TCP4
04XL
Dimensions
Length: 298.5 mm
(11.75 inches)
330 mm (13.00 inches) 375 mm (14.75 inches) 375 mm (14.75 inches)
Width: 298.5 m m
(11.75 inches)
254 mm (10.00 inches) 318 mm (12.50 inches) 318 mm (12.50 inches)
Height:
254 mm (10.00 inches) 108 mm (4.25 inches) 127 mm (5.00 inches) 127 mm (5.00 inches)
Weight
2.7 kg (6.00 lb) 0.585 kg (1.29 lb) 1.33 kg (2.93 lb) 1.55 kg (3.42 lb)
50 TCPA300/400 Amplifiers and TCP300/400 Series Current Probes User Manual
