Specifications
These specifications are v alid only under the following conditions:
The probe and amplifier have been calibrated at an ambient temperature of
23 ° ±5 °C.
The probe and amplifier are operating within the environmental limits
described in Table 4-6 on page 4-5 (the operating temperature limits are 0 °C
to +50 °C, unless otherwise stated).
The probe and amplifier have had a warm-up period of at least 20 minutes.
The probe degauss/autobalance routine has been performed after the
20-minute warm-up period, and thereafter whenever the PROBE
DEGAUSS/AUTOBALANCE light blinks.
The amplifier output is properly terminated into 50 Ω.
Specifications are separated into two categories: warranted specifications and
nominal or typical characteristics.
Wa rra
nted Specifications
Warranted specifications, Table 4-1, are guaranteed performance specifications
unless specifically designated as typical or nominal.
Tabl
e 7: Warranted TCPA300 and TCPA400 specifications
Amplifier TCPA300 TCPA400
DC G a in Accuracy ≤1% ≤1%
Installed probe TCP312 TCP305 TCP303 TCP404XL
Bandwidth (-3 dB) DC to 100 MHz DC to 50 MHz DC to 15 MHz DC to 2 MHz
Rise Time, 10% to
90%
≤3
.5 ns
≤7ns
≤2
3ns
≤1
75 ns
DC Gain Accuracy:
Warranted
≤3% ≤3% ≤3%
1
≤3%
Typical
2
≤1% ≤1% ≤1% ≤1%
1
Warranted from 10 °C to 50 °C. For temperature range of 0 °C to <10 °C, spec is +3%/-6%.
2
23 °C ±5 °C
TCPA300/400 Amplifiers and TCP300/400 Series Current Probes User Manual 47
