Specifications
Table 8: Nominal and typical amplifier characteristics (cont.)
Installed probe
Parameter TCP312 TCP305 TCP303 TCP404XL
Low Current Sensitivity
Range
1 A/V Range 5 A /V Range 5 A/V Range N/A
DC (continuous)
5A 25A 25A
—
DC (noncontinuous) N/A N/A N/A
—
RMS (sinusoidal)
3.5 A 17.7 A 17.7 A
—
Peak Pulse 50 A 50 A 500 A
—
Input Voltage
100-240 VAC (±10%), 47 Hz to 440 Hz, s ingle phase
Maximum Power 50 Watts maximum
Fuse Rating
3.15 AH, 250 V (Not operator-replaceable.)
1
Includes probe, amplifier, and TEKPROBE-to-TEKPROBE interface cable or 012-0117-xx BNC cable.
Mecha
nical Characteristics
Table 9: TCPA300 and TCPA400 mechanical characteristics
Para
meter, nominal
Char
acteristic
Length
173
mm (6.8 in)
Width
91.
4mm(3.6in)
Height
16
7mm(6.6in)
Weight
1.
14 kg (2.5 lb)
TCPA300/400 Amplifiers and TCP300/400 Series Current Probes User Manual 49
