Removal and Replacement
TDS 340A, TDS 360 & TDS 380 T
echnical Reference
6–19
Press latch
to release
View A
Ground spring
Rear of front panel
ESD shield
Front panel
board
Menu button
elastomer
Knobs and
shafts
Flex the latches (3) downward to
release board. Then, rotate the
board and pull it down.
See View A
Figure 6–10: Disassembly of front-panel assembly
