TDS 340A, TDS 360 & TDS 380 Technical Reference
2–1
Operating Information
This chapter identifies and describes each control and connector on the TDS 300
Series oscilloscope. This chapter also describes how to use the oscilloscope
menu system. Refer to the TDS 340A, TDS 360 & TDS 380 User Manual for
more information on setting up and taking measurements with the oscilloscope.
Display and Power Controls
The ON/STBY button toggles
instrument power.
The Side Menu buttons provide
access to side menu selections.
Refer to page 2–7 for more
information about the user interface
Side Menu.
The CLEAR MENU button clears
all menus from the screen.
The Main Menu buttons provide access to
main menu selections. Refer to page 2–7
for more information about the user interface
Main Menu.
