Tektronix TDS 520B Service Manual

Performance Tests
TDS 500B, 600B and TDS 700A Service Manual
4–19
TDS 600B Test Record
Photocopy this and the next three pages and use them to record the performance
test results for your TDS 600B.
TDS 600B Test Record
Instrument Serial Number: Certificate Number:
Temperature: RH %:
Date of Calibration: Technician:
TDS 600B Performance Test Minimum Incoming Outgoing Maximum
Offset Accuracy
CH1 Offset +1 mV
+101 mV
+1.01 V
– 1.45 mV
– 69.1 mV
– 691 mV
__________
__________
__________
__________
__________
__________
+ 1.45 mV
+ 69.1 mV
+ 691 mV
CH2 Offset +1 mV
+101 mV
+1.01 V
– 1.45 mV
– 69.1 mV
– 691 mV
__________
__________
__________
__________
__________
__________
+ 1.45 mV
+ 69.1 mV
+ 691 mV
CH3 or AX1 +1 mV
Offset +101 mV
+1.01 V
– 1.45 mV
– 69.1 mV
– 691 mV
__________
__________
__________
__________
__________
__________
+ 1.45 mV
+ 69.1 mV
+ 691 mV
CH4 or AX2 +1 mV
Offset +101 mV
+1.01 V
– 1.45 mV
– 69.1 mV
– 691 mV
__________
__________
__________
__________
__________
__________
+ 1.45 mV
+ 69.1 mV
+ 691 mV
DC Voltage Measurement Accuracy (Averaged)
CH1 5 mV Vert scale setting,
–5 Div position setting, +1 V offset
+ 1.029 V __________ __________ + 1.0513 V
CH1 5 mV Vert scale setting,
+5 Div position setting, –1 V offset
– 1.0513 V __________ __________ – 1.029 V
CH1 200 mV Vert scale setting,
–5 Div position setting, +10 V offset
+ 11.420 V __________ __________ + 11.786 V
CH1 200 mV Vert scale setting,
+5 Div position setting, –10 V offset
– 11.786 V __________ __________ – 11.420 V
CH1 1 V Vert scale setting,
–5 Div position setting, +10 V offset
+ 17.26 V __________ __________ + 18.76 V
CH1 1 V Vert scale setting,
+5 Div position setting, –10 V offset
– 18.76 V __________ __________ – 17.26 V
CH2 5 mV Vert scale setting,
–5 Div position setting, +1 V offset
+ 1.029 V __________ __________ + 1.0513 V
CH2 5 mV Vert scale setting,
+5 Div position setting, –1 V offset
– 1.0513 V __________ __________ – 1.029 V
CH2 200 mV Vert scale setting,
–5 Div position setting, +10 V offset
+ 11.420 V __________ __________ + 11.786 V
