Tektronix TDS 520B - Table 1-14: Warranted Characteristics - Environmental

Warranted Characteristics
TDS 500B, 600B and TDS 700A Service Manual
1–19
Table 1–13: Warranted Characteristics — Output Ports, Probe Compensator, and Power Requirements (Cont.)
Name Description
Ou
t
pu
t Vo
l
t
age
a
n
d
F
re
q
ue
n
cy
,
Pr be pe a r
Characteristic Limits
Pr
o
be
Com
pe
ns
a
to
r
Output Voltage
Frequency
0.5 V (base-top) ±1% into a ≥50  load
1 kHz ±5%
Output Voltage, Signal Out (CH 3
1
) For TDS 600B: 20 mV/division ±20% into a 1 M load;
10 mV/division ±20% into a 50  load
For TDS 500B/700A:
22 mV/division ±20% into a 1 M load;
11 mV/division ±20% into a 50  load
Source Voltage 90 to 250 VAC
RMS
, continuous range
TDS 500B/700A: category II
Source Frequency 45 Hz to 440 Hz
Power Consumption ≤300 W (450 VA)
1
CH 3 signal out is present at the rear panel if CH 3 (AUX 1 on the TDS 620B or 680B) is selected as the trigger source for
the main and/or delayed trigger systems. It is not available when a channel other than CH3 (AUX 1 on the TDS 620B or
680B) is the source for the Video Trigger when Option 05 is installed.
Table 1–14: Warranted Characteristics — Environmental
Name Description
Atmospherics Temperature (no diskette in floppy drive):
TDS 600B: Operating: +4_ C to +45_ C
TDS 500B/700A: Operating: +4_ C to +50_ C
Nonoperating: –22_ C to +60_ C
Relative humidity (no diskette in floppy drive):
Operating: 20% to 80%, at or below +32_ C,
upper limit derates to 30% relative humidity at +45_ C
Nonoperating: 5% to 90%, at or below +41_ C,
upper limit derates to 30% relative humidity at 60_ C
Altitude:
To 4570 m (15,000 ft.), operating
To 12190 m (40,000 ft.), nonoperating
Dynamics Random vibration (floppy diskette not installed):
0.31 g rms, from 5 to 500 Hz, 10 minutes each axis, operating
3.07 g rms, from 5 to 500 Hz, 10 minutes each axis, nonoperating
