Warranted Characteristics
TDS 500C, TDS 600B & TDS 700C Performance Verification and Specifications
2–21
Table 2–13: Warranted characteristics — Output ports, probe compensator, and power requirements (cont.)
Name Description
Out
ut Vo
t
g
nd F
qu
n
y,
Characteristic Limits
o
Co
ns
to
Output Voltage
Frequency
0.5 V (base-top) ±1% into a ≥50 load
1 kHz ±5%
Output Voltage, Signal Out (CH 3
1
) For TDS 600B: 20 mV/division ±20% into a 1 M load;
10 mV/division ±20% into a 50 load
For TDS 500C/700C:
22 mV/division ±20% into a 1 M load;
11 mV/division ±20% into a 50 load
Source Voltage 90 to 250 VAC
RMS
, continuous range, CAT II
Source Frequency 45 Hz to 440 Hz
Power Consumption ≤300 W (450 VA)
1
CH 3 signal out is present at the rear panel if CH 3 (AUX 1 on the TDS 620B or 680B) is selected as the trigger source for
the main and/or delayed trigger systems. It is not available when a channel other than CH3 (AUX 1 on the TDS 620B or
680B) is the source for the Video Trigger when Option 05 is installed.
