Performance Tests
TDS 500C, TDS 600B & TDS 700C Performance Verification and Specifications
1–19
TDS 600B Test Record
Photocopy this and the next three pages and use them to record the performance
test results for your TDS 600B.
TDS 600B Test Record
Instrument Serial Number: Certificate Number:
Temperature: RH %:
Date of Calibration: Technician:
TDS 600B Performance Test Minimum Incoming Outgoing Maximum
Offset Accuracy
CH1 Offset +1 mV
+101 mV
+1.01 V
– 2.1 mV
– 75.6 mV
– 756 mV
__________
__________
__________
__________
__________
__________
+ 2.1 mV
+ 75.6 mV
+ 756 mV
CH2 Offset +1 mV
+101 mV
+1.01 V
– 2.1 mV
– 75.6 mV
– 756 mV
__________
__________
__________
__________
__________
__________
+ 2.1 mV
+ 75.6 mV
+ 756 mV
CH3 or AX1 +1 mV
Offset +101 mV
+1.01 V
– 2.1 mV
– 75.6 mV
– 756 mV
__________
__________
__________
__________
__________
__________
+ 2.1 mV
+ 75.6 mV
+ 756 mV
CH4 or AX2 +1 mV
Offset +101 mV
+1.01 V
– 2.1 mV
– 75.6 mV
– 756 mV
__________
__________
__________
__________
__________
__________
+ 2.1 mV
+ 75.6 mV
+ 756 mV
DC Voltage Measurement Accuracy (Averaged)
CH1 5 mV Vert scale setting,
–5 Div position setting, +1 V offset
+ 1.0329 V __________ __________ + 1.0471 V
CH1 5 mV Vert scale setting,
+5 Div position setting, –1 V offset
– 1.0471 V __________ __________ – 1.0329 V
CH1 200 mV Vert scale setting,
–5 Div position setting, +10 V offset
+ 11.4165 V __________ __________ + 11.7835 V
CH1 200 mV Vert scale setting,
+5 Div position setting, –10 V offset
– 11.7835 V __________ __________ – 11.4165 V
CH1 1 V Vert scale setting,
–5 Div position setting, +10 V offset
+ 17.2425 V __________ __________ + 18.7575 V
CH1 1 V Vert scale setting,
+5 Div position setting, –10 V offset
– 18.7575 V __________ __________ – 17.2425 V
CH2 5 mV Vert scale setting,
–5 Div position setting, +1 V offset
+ 1.0329 V __________ __________ + 1.0471 V
CH2 5 mV Vert scale setting,
+5 Div position setting, –1 V offset
– 1.0471 V __________ __________ – 1.0329 V
CH2 200 mV Vert scale setting,
–5 Div position setting, +10 V offset
+ 11.4165 V __________ __________ + 11.7835 V
