Tektronix TDS 600B Performance Verification Manual

Performance Tests
1–18
TDS 500C, TDS 600B & TDS 700C Performance Verification and Specifications
Table 1–1: Test equipment (cont.)
Item number and
description
PurposeExampleMinimum requirements
27. Generator, Optical Im-
pulse
850 nm optical impulse Tektronix OIG501 Optical
Impulse Generator
1
Checking Option 3C
28. Generator, Optical Im-
pulse
1300 nm optical impulse Tektronix OIG502 Optical
Impulse Generator
1
Checking Option 4C
29. Attenuator, Optical 62.5 micron optical attenuator Tektronix OA5022 Optical
Attenuator
1
Checking Option 3C and 4C
30. Cable, Fibre Optic FC-FC fiber cable 174-2322-00 Checking Option 3C and 4C
31. Optical-to-Electrical
Converter
P6701B (used with Option 3C) or
P6703B (used with Option 4C)
optical-to-electrical converter
Tektronix part number
P6701B or P6703B
Checking Option 3C and 4C
1
Requires a TM 500 or TM 5000 Series Power Module Mainframe.
2
Warning: The P6243 and P6245 probes that may be used with this oscilloscope provide an extremely low loading
capacitance (<1 pF) to ensure the best possible signal reproduction. These probes should not be used to measure
signals exceeding ±8 V, or errors in signal measurement will be observed. Above 40 V, damage to the probe may result.
To make measurements beyond ±8 V, use either the P6139A probe (good to 500 V), or refer to the catalog for a recom-
mended probe.
3
You can replace items 19, 20, or 21 with a Tegam/Tektronix SG503 (item 25) or SG504 (item 26) – if available.
