Tektronix TDS 600B

Performance Tests
1–26
TDS 500C, TDS 600B & TDS 700C Performance Verification and Specifications
TDS 500C/700C Test Record (Cont.)
Instrument Serial Number: Certificate Number:
Temperature: RH %:
Date of Calibration: Technician:
TDS 500C/700C Performance Test MaximumOutgoingIncomingMinimum
CH 3 or AX 1 SIGNAL OUTPUT, 1 M Pk-Pk ≥ 88 mV __________ __________ Pk-Pk ≤ 132 mV
CH 3 or AX 1 SIGNAL OUTPUT, 50  Pk-Pk ≥ 44 mV __________ __________ Pk-Pk ≤ 66 mV
Probe Compensator Output Signal
Frequency (CH1 Freq). 950 Hz __________ __________ 1.050 kHz
Voltage (difference) 495 mV __________ __________ 505 mV
