Tektronix TDS 600B Performance Verification Manual

Performance Tests
TDS 500C, TDS 600B & TDS 700C Performance Verification and Specifications
1–77
PAL signal
source
Digitizing Oscilloscope
75  cable
75  terminator
Output
Figure 1–35: Line count accuracy test hookup
H Press the main-menu Trigger Position.
H Press the side-menu to Set to 50%.
H Press the main-menu to Horiz Pos.
H Press the side-menu to Set to 50%.
H Use the HORIZONTAL POSITION knob to move the falling edge
of the sync pulse to two divisions to the left of center screen. See
Figure 1–36.

Tektronix TDS 600B Specifications

General

Brand	Tektronix
Model	TDS 600B
Category	Test Equipment
Language	English
