Tektronix TDS 684A User Manual

Appendix D: Factory Initialization Settings
TDS 500B, TDS 600B, & TDS 700A User Manual
D–3
Table D–1: Factory Initialization Defaults (Cont.)
Control Changed by Factory Init to
Edge trigger slope Rising
Edge trigger source Channel 1
GPIB parameters No change
Hardcopy Format
Layout
Palette
Port
Unchanged
Unchanged
Unchanged
Unchanged
Horizontal – delay time/division 50 s
Horizontal – delay trigger position 50%
Horizontal – delay trigger record length 500 points (10 divs)
Horizontal – FastFrame TDS 500B & TDS 700A: Off
Horizontal – FastFrame, frame count TDS 500B & TDS 700A: 2
Horizontal – FastFrame, frame length TDS 500B & TDS 700A: 500
Horizontal – fit to screen Off
Horizontal – main time/division 500 s
Horizontal – main trigger position 50%
Horizontal – main trigger record length 500 points (10 divs)
Horizontal – time base Main only
Limit template ±V Limit
±H Limit
40 mdiv
40 mdiv
Limit template destination Ref1
Limit template source Ch1
Limit test sources Ch1 compared to Ref1;
all others compared to none.
Limit testing Off
Limit testing – hardcopy if condition met Off
Limit testing – ring bell if condition met Off
Logic pattern trigger Ch4 (Ax2) input X (don’t care)
Logic state trigger Ch4 (Ax2) input Rising edge
Logic trigger class Pattern
Logic trigger input
(pattern and state)
Channel 1 = H (high),
Channels 2 & 3 (Ax1) = X (don’t care)
Logic trigger logic
(pattern and state)
AND
