Operating Instructions

TDS 500B, 600B and TDS 700A Service Manual

2–9

Most functions can be set either by using one (or two) front-panel button(s) or

knob(s), or by pushing a front-panel button to use a main menu, and then a

side-menu button to set the function. The following steps illustrate both

procedures.

1. Locate the block that contains the function to be set.

Special function controls.

Access all functions except

vertical, horizontal, and

trigger functions from this

front-panel control block.

Vertical function controls. Access all

vertical functions and inputs from

this front-panel control block.

Horizontal function controls.

Access all horizontal functions

from this front-panel block.

Trigger function controls.

Access all trigger functions

from this front-panel block.

How to Set Functions
