Command Descriptions
2−44
TDS200/1000/2000 Series Oscilloscope Programmer Manual
AUTOSet:VIEW
NOTE. You can use this command ONLY with the TDS1000 and
TDS2000 series.
Sets and queries the current view.
If the current menu is not the Autoset menu, or if the view is not
valid for the detected waveform, the set command causes the
oscilloscope to generate error 221 (Settings conflict).
Miscellaneous
AUTOSet:VIEW { MULTICYcle | SINGLECYcle | FFT |
RISINGedge | FALLINGedge | FIELD | ODD | EVEN | LINE |
LINENum | DCLIne | DEFault | NONE }
MULTICYcle
Sine or square display of several cycles. Default for sine-like and
square-like signals.
SINGLECYcle
Sine or square display of approximately one cycle.
FFT
FFT of a sine wave.
RISINGedge
Display of the rising edge of a square wave.
FALLINGedge
Display of the falling edge of a square wave.
FIELD
Video signal display that is synced on all fields. Default for video
signals.
Group
Syntax
Arguments
